Optoma Projector overheating problem – Failing Fan – mega easy fix!!

I bought an “Optoma H181x Full 3D HD Projector” back in 2015, and it’s been awesome for 7 years. No issues at all, just many happy hours of HD and 3D movie & TV watching.

Recently though, it started to overheat and switch itself off after just a couple of minutes running, with the ominous message “Fan locked. Projector will switch off automatically. Please contact service centre for repair”.

Looking around online I could see it was a common problem in older projectors, usually due to dust buildup, and sorted by either cleaning or replacing the fan.

I tried to clean the fan but it wasn’t very dirty and made no difference. Looking through the front vents with a torch, I could see the fan was trying to turn on startup, then giving up. It’s a pretty ordinary component but taking the projector apart sounded dangerous (many reports of this going badly for others) and after a partial attempt I decided it wasn’t something I was comfortable or confident doing…. too many hidden clips and other parts needing disconnected or removed, like the IR receiver, the switches, the zoom/focus wheel, etc.

This pic shows the top panel removed (just one captive screw on the left of the cover needs undone, then it slides left and lifts up & off easily.). Note: there’s a sensor that prevents the projector from powering on while this cover is removed.

You can see the culprit fan lurking behind that yellow tape, it cools the bulb housing. To get anywhere near it I had to disconnect the wires via the plastic molex/clip on the left, remove those three screws on the right, then carefully lift the bulb housing out (straight upwards), using the little metal handle with one hand and guiding the heat shields/flaps past the top of the cover with the other.

With that out of the way you can now see one side of the fan, but you can’t remove it from this side – here’s a close up pic:

I noticed the fan blades were stiffer and harder to rotate (by hand) than they probably should be, and I knew fans like these could sometimes be cleaned and lubricated… this sounded worth a shot (it was looking like ‘new projector time’ otherwise), but that cover was stuck down fast….

This pic shows the same side of the fan after I scraped off the cover to reveal four small holes. I then carefully placed 2-3 drops of ordinary multi-purpose oil in each hole. I let the projector stand in this position for a while, so the oil could work its way in/down, then cleaned the surface with Isopropyl Alcohol to remove any excess oil, before sticking some insulating tape back where the original label/cover had been. My projector sits up high and points downwards and I didn’t want any oil escaping…. or dripping on to the lamp.

I replaced the lamp housing and the cover and gave it a whirl – it’s now starting up first time no problem and running smoothly and quietly, just like it used to!

I think the placement of the fan, especially when the projector points downwards, means the fans central bearing is exposed to a lot of heat, which dries it out over time. It’s given many hours of use over the past 7 years so I’m not complaining, and hopefully I’ll get some more use out of it now.

This all took me quite a while to figure out and think through, but the actual fix was really easy and took about 10 minutes.

I thought I’d share this for anyone else facing the same issue.

Cheers,

Don

Lockdown lumber

Some pics of a fallen beech tree being chopped up for firewood and milling.

One half of this tree had fallen on a neighbours track, and I spent a sunny afternoon self-isolating with it and a couple of chainsaws.

The “before” pics… it looks like a branch in these shots, but it was quite a lot of wood.

After some limbing and bucking and a mild case of sunburn:

Gear – the Husqvarna 365 with its 20″ bar on and a recent chain from chainsawbars did almost all of the work no problem. My old Mountfield was having an off-day.

Root cause analysis – the lower 4 foot was rotten through.
The other half of the tree is still standing and looks to be ok though.

The good bits – I left these nice and straight looking 6 and 4 foot sections in place to bring home with the tractor later.
The ends have been sealed and I plan to mill them in to 2″ planks and maybe some thicker slabs

The (panoramic) aftermath

And a truck full (ok, not quite, it was a long afternoon) of firewood that was delivered to a neighbour

Random Landy pics

Kubernetes – adding persistent storage to the Cluster

Previously

In the last Kubernetes post…

I wrote about getting Helm and Tiler working on the Kubernetes Cluster I set up here…

There was an obvious flaw in the example MySQL Chart I deployed via Helm and Tiller, in that the required Persistent Volume Claims could not be satisfied so the pod was stuck in a “Pending” state for ever.

Adding Persistent Storage

In this post I will sort that out, by adding Persistent Storage to the Cluster and redeploying and testing the same Chart deployed via “helm deploy stable/mysql“. This time, it should be able to claim all of the resources it needs with no tweaking or hints supplied…

First a few notes on some of the commands and tools I used for troubleshooting what was wrong with the mysql deploy.

watch -d 'sudo kubectl get pods --all-namespaces -o wide'

watch -d kubectl describe pod wise-mule-mysql

kubectl attach wise-mule-mysql-d69788f48-zq5gz -i

The above commands showed a pod that generally wasn’t happy or connectable, but little detail.

Running “kubectl get events -w” is much more informative:

LAST SEEN   TYPE      REASON              KIND                    MESSAGE
17m         Warning   FailedScheduling    Pod                     pod has unbound immediate PersistentVolumeClaims
17m         Normal    SuccessfulCreate    ReplicaSet              Created pod: quaffing-turkey-mysql-65969c88fd-znwl9
2m38s       Normal    FailedBinding       PersistentVolumeClaim   no persistent volumes available for this claim and no storage class is set
17m         Normal    ScalingReplicaSet   Deployment              Scaled up replica set quaffing-turkey-mysql-65969c88fd to 1

and doing “kubectl describe pod <pod name>” is also very useful:

<snip a whole load of events and details>
  Type     Reason            Age                    From               Message
  ----     ------            ----                   ----               -------
  Warning  FailedScheduling  5m26s (x2 over 5m26s)  default-scheduler  pod has unbound immediate PersistentVolumeClaims

Making it pretty clear what’s going on and exactly what is noticeably absent from the Cluster.

My initial plan had been to use GlusterFS and Heketi, but having dabbled with this before and knowing it wasn’t really something I wanted to do for this use case, it was a bit of Yak Shaving I’d really like to avoid if possible.

So, I had a look around and found “Rook“. This sounded much simpler and more suited to my needs. It’s also open source, Apache licensed, and works on multi-node clusters. I’d previously considered using hostPath storage but it’s a bit too basic even for here, and would restrict me to a single node cluster due to the (lack of) replication, missing a lot of the point of a Cluster, so I thought I’d give Rook a shot.

Here’s the guide on deploying Rook that I used:

https://github.com/hobby-kube/guide#deploying-rook

Which says to

Apply the storage manifests in the following order:

storage/00-namespace.yml

storage/operator.yml (wait for the rook-agent pods to be deployed kubectl -n rook get pods before continuing)

storage/cluster.yml

storage/storageclass.yml

storage/tools.yml

I tried to follow this but had some issues, which I will try and clarify when I run through this again – I’d made a bit of a mess trying a bit of Gluster and some hostPath and messing about with the default storage class etc, so it was quite possibly “just me”, and not Rook to blame here 🙂 This is some of my shell history:

kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-operator.yaml
kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-cluster.yaml
kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-storageclass.yaml
kubectl -n rook get pods
kubectl apply -f https://github.com/hobby-kube/manifests/blob/master/storage/00-namespace.yml
kubectl apply -f https://github.com/hobby-kube/manifests/blob/master/storage/00-namespace.yml
kubectl apply -f https://github.com/hobby-kube/manifests/blob/master/storage/00-namespace.yml
kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-operator.yaml
kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-cluster.yaml
watch -d 'sudo kubectl get pods --all-namespaces -o wide'
kubectl apply -f https://raw.githubusercontent.com/rook/rook/release-0.5/cluster/examples/kubernetes/rook-storageclass.yaml

I definitely ran through this more than once, and I think it also took a while for things to start up and work – the subsequent runs went much better than the initial ones anyway. I also applied a few patches to the rook user and storage class (below) – these and many other alternatives were recommended by others facing similar sounding issues, but I think for me the fundamental is solved further below, re the rbd binary missing from $PATH, and installing ceph:


kubectl get secret rook-rook-user -oyaml | sed "/resourceVer/d;/uid/d;/self/d;/creat/d;/namespace/d" | kubectl -n kube-system apply -f -

kubectl get secret rook-rook-user -oyaml | sed "/resourceVer/d;/uid/d;/self/d;/creat/d;/namespace/d" | kubectl -n default -f -
 kubectl get secret rook-rook-user -oyaml | sed "/resourceVer/d;/uid/d;/self/d;/creat/d;/namespace/d" | kubectl -n default apply -f -
  kubectl patch storageclass rook-block -p '{"metadata":{"annotations": {"storageclass.kubernetes.io/is-default-class": "true"}}}

That all done, I still had issues with my pods, specifically this error:

MountVolume.WaitForAttach failed for volume “pvc-4895a379-104b-11e9-9d98-000c29702bc8” : fail to check rbd image status with: (executable file not found in $PATH), rbd output: ()

which took me a little while to figure out. I think reading this page on RBD gave me the hint that there was something (well yeah, the rbd binary specifically) missing on the hosts, but there’s a lot of talk of folk solving this by creating custom images with the rbd binary added to the $PATH in them, replacing core k8s containers with them, which didn’t sound too appealing to me. I had assumed that the images would include the binaries, but hadn’t checked this is any way.

This issue may well be part or possibly all of the reason why I ran the above commands repeatedly and applied all of those patches.

The simple yet not too obvious solution to this – in my case anyway – was to ensure that the ceph common package was available both on the master:

apt-get update && apt-get install ceph-common -y

and critically that it was also available on each of the worker nodes too.

Once that was done, I think I deleted and reapplied everything rook-related again, then things started working as they should, finally.

A quick check:

ansible@umaster:~$ kubectl get sc
NAME PROVISIONER AGE
rook-block (default) rook.io/block 22h

And things are looking much better now.

Checking the Dashboard I can see a Rook namespace with a number of Rook pods all looking green, and Persistent Volume Claims in the default namespace too:

Test with an example – “helm install stable/mysql”, take 2…

To verify this I re ran the same Helm Chart for mysql, with no changes or overrides, to ensure that rook provisioning was working, that it was properly detected and used as the default storage class in the Cluster with no args/hints needed.

The output from running “helm install stable/mysql” includes this info:


MySQL can be accessed via port 3306 on the following DNS name from within your cluster:
donmysql.default.svc.cluster.local

To get your root password run:

    MYSQL_ROOT_PASSWORD=$(kubectl get secret –namespace default donmysql -o jsonpath=”{.data.mysql-root-password}” | base64 –decode; echo)

To connect to your database:

1. Run an Ubuntu pod that you can use as a client:

    kubectl run -i –tty ubuntu –image=ubuntu:16.04 –restart=Never — bash -il

2. Install the mysql client:

    $ apt-get update && apt-get install mysql-client -y

3. Connect using the mysql cli, then provide your password:
    $ mysql -h donmysql -p

So I tried the above, opting to create an ubuntu client pod, installing mysql utils to that then connecting to the above MySQL instance with the root password like so:

ansible@umaster:~$  MYSQL_ROOT_PASSWORD=$(kubectl get secret --namespace default donmysql  -o jsonpath="{.data.mysql-root-password}" | base64 --decode; echo)
ansible@umaster:~$ echo $MYSQL_ROOT_PASSWORD
<THE ROOT PASSWORD WAS HERE>
ansible@umaster:~$ kubectl run -i --tty ubuntu --image=ubuntu:16.04 --restart=Never -- bash -il
If you don't see a command prompt, try pressing enter.
root@ubuntu:/#
root@ubuntu:/# apt-get update && apt-get install mysql-client -y
Get:1 http://archive.ubuntu.com/ubuntu xenial InRelease [247 kB]
Get:2 http://security.ubuntu.com/ubuntu xenial-security InRelease [107 kB]
<snip a load of boring apt stuff>
Setting up mysql-common (5.7.24-0ubuntu0.16.04.1) ...
update-alternatives: using /etc/mysql/my.cnf.fallback to provide /etc/mysql/my.cnf (my.cnf) in auto mode
Setting up mysql-client-5.7 (5.7.24-0ubuntu0.16.04.1) ...
Setting up mysql-client (5.7.24-0ubuntu0.16.04.1) ...
Processing triggers for libc-bin (2.23-0ubuntu10) ...
root@ubuntu:/# mysql -h donmysql -p
Enter password:
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 67
Server version: 5.7.14 MySQL Community Server (GPL)
<snip some more boring stuff>
mysql> show databases;
+--------------------+
| Database           |
+--------------------+
| information_schema |
| mysql              |
| performance_schema |
| sys                |
+--------------------+
4 rows in set (0.00 sec)
mysql> exit
Bye
root@ubuntu:/

In the Kubernetes Dashboard (loads more on that little adventure coming soon!) I can also see that the MySQL Pod is Running and looks happy, no more Pending or Init issues for me now:

and that the Rook Persistent Volume Claims are present and looking healthy too:

Conclusion & next steps

That’s storage sorted, kind of – I’m not totally happy everything I did was needed, correct and repeatable yet, or that I know enough about this.

Rook.io looks very good and I’m happy it’s the best solution for my current needs, but I can see that I should have spent more time reading the documentation and thinking about prerequisites, yadda yadda. To be honest when it comes to storage I’m a bit of a Luddite – i just want it to be there and work as I’d expect it to, and I was keen to move on to the next steps….

I plan to scrub the k8s cluster shortly and run through this again from scratch to make sure I’ve got it clear enough to add to my provisioning pipeline process.

Next, a probably not-too-brief post on how I got Heapster stats working with an InfluxDB backend monitoring stats for both the Master and Nodes, installing a usable Kubernetes Dashboard, and getting that working with suitable access/permissions, aaaaand getting the k8s Dashbaord showing the CPU and Memory stats from Heapster as seen in the Dashboard pic of the pod statuses above…. phew!

Kubernetes – adding Helm and Tiller and deploying a Chart

Introduction

This is Step 3 in my recent series of Kubernetes blog posts.

Step 1 covers the initial host creation and basic provisioning with Ansible: https://www.donaldsimpson.co.uk/2019/01/03/kubernetes-setting-up-the-hosts/

Step 2 details the Kubernetes install and putting the cluster together, as well as reprovisioning it: https://www.donaldsimpson.co.uk/2018/12/29/kubernetes-from-cluster-reset-to-up-and-running/

Caveat

My aim here is to create a Kubernetes environment on my home lab that allows me to play with k8s and related technologies, then quickly and easily rebuild the cluster and start over.

The focus here in on trying out new technologies and solutions and in automating processes, so in this particular context I am not at all bothered with security, High Availability, redundancy or any of the usual considerations.

Helm and Tiller

The quick start guide is very good: https://docs.helm.sh/using_helm/ and I used this as I went through the process of installing Helm, initializing Tiller and deploying it to my Kubernetes cluster, then deploying a first example Chart to the Cluster. The following are my notes from doing this, as I plan to repeat then automate the entire process and am bound to forget something later 🙂

From the Helm home page, Helm describes itself as

The package manager for Kubernetes

and states that

Helm is the best way to find, share, and use software built for Kubernetes.

I have been following this project for a while and it looks to live up to the hype – there’s a rapidly growing and pretty mature collection of Helm Charts available here: https://github.com/helm/charts/tree/master/stable which as you can see covers an impressive amount of things you may want to use in your own Kubernetes cluster.

Get the Helm and Tiller binaries

This is as easy as described – for my architecture it meant simply

wget https://storage.googleapis.com/kubernetes-helm/helm-v2.12.1-linux-amd64.tar.gz

and extract and copy the 2 binaries (helm & tiller) to somewhere in your path

I usually do a quick sanity test or 2 – e.g. running “which helm” as a non-root user and maybe check “helm –help” and “helm version” all say something sensible too.

Install Tiller

Helm is the Client side app that directs Tiller, which is the Server side part. Just like steering a ship… and stretching the Kubernetes nautical metaphors to the max.

Tiller can be installed to your k8s Cluster simply by running “helm init“, which should produce output like the following:


ansible@umaster:~/helm$ helm init
Creating /home/ansible/.helm
Creating /home/ansible/.helm/repository
Creating /home/ansible/.helm/repository/cache
Creating /home/ansible/.helm/repository/local
Creating /home/ansible/.helm/plugins
Creating /home/ansible/.helm/starters
Creating /home/ansible/.helm/cache/archive
Creating /home/ansible/.helm/repository/repositories.yaml
Adding stable repo with URL: https://kubernetes-charts.storage.googleapis.com
Adding local repo with URL: http://127.0.0.1:8879/charts
$HELM_HOME has been configured at /home/ansible/.helm.
Tiller (the Helm server-side component) has been installed into your Kubernetes Cluster
Please note: by default, Tiller is deployed with an insecure 'allow unauthenticated users' policy.
To prevent this, run `helm init` with the --tiller-tls-verify flag.
For more information on securing your installation see: https://docs.helm.sh/using_helm/#securing-your-helm-installation
Happy Helming

That should do it, and a quick check of running pods confirms we now have a tiller pod running inside the kubernetes cluster in the kube-system namespace:

ansible@umaster:~/helm$ sudo kubectl get pods --all-namespaces -o wide
NAMESPACE     NAME                              READY   STATUS    RESTARTS   AGE     IP             NODE       NOMINATED NODE   READINESS GATES
kube-system   coredns-86c58d9df4-mg8b9          1/1     Running   0          22h     10.244.0.11    umaster    <none>           <none>
kube-system   coredns-86c58d9df4-zv24d          1/1     Running   0          22h     10.244.0.10    umaster    <none>           <none>
kube-system   etcd-umaster                      1/1     Running   0          22h     192.168.0.46   umaster    <none>           <none>
kube-system   kube-apiserver-umaster            1/1     Running   0          22h     192.168.0.46   umaster    <none>           <none>
kube-system   kube-controller-manager-umaster   1/1     Running   0          22h     192.168.0.46   umaster    <none>           <none>
kube-system   kube-flannel-ds-amd64-2npnw       1/1     Running   0          14h     192.168.0.46   umaster    <none>           <none>
kube-system   kube-flannel-ds-amd64-lpphn       1/1     Running   0          7m13s   192.168.0.43   ubuntu01   <none>           <none>
kube-system   kube-proxy-b7rwv                  1/1     Running   0          22h     192.168.0.46   umaster    <none>           <none>
kube-system   kube-proxy-wqw8c                  1/1     Running   0          7m13s   192.168.0.43   ubuntu01   <none>           <none>
kube-system   kube-scheduler-umaster            1/1     Running   0          22h     192.168.0.46   umaster    <none>           <none>
kube-system   tiller-deploy-6f8d4f6c9c-v8k9x    1/1     Running   0          112s    10.244.1.21    ubuntu01   <none>           <none>

So far so nice and easy, and as per the docs the next steps are to do a repo update and a test chart install…

ansible@umaster:~/helm$ helm repo update
Hang tight while we grab the latest from your chart repositories…
…Skip local chart repository
…Successfully got an update from the "stable" chart repository
Update Complete. ⎈ Happy Helming!⎈
ansible@umaster:~/helm$ helm install stable/mysql
Error: no available release name found
ansible@umaster:~/helm$

Doh. A quick google makes that “Error: no available release name found” look like a k8s/helm version conflict, but the fix is pretty easy and detailed here: https://github.com/helm/helm/issues/3055


So I did as suggested, creating a service account cluster role binding and patch to deploy them to the kube-system namespace:

kubectl create serviceaccount --namespace kube-system tiller
kubectl create clusterrolebinding tiller-cluster-rule --clusterrole=cluster-admin --serviceaccount=kube-system:tiller
kubectl patch deploy --namespace kube-system tiller-deploy -p '{"spec":{"template":{"spec":{"serviceAccount":"tiller"}}}}'

and all then went ok:

ansible@umaster:~/helm$ kubectl create serviceaccount --namespace kube-system tillerserviceaccount/tiller created

ansible@umaster:~/helm$ kubectl create clusterrolebinding tiller-cluster-rule --clusterrole=cluster-admin --serviceaccount=kube-system:tillerclusterrolebinding.rbac.authorization.k8s.io/tiller-cluster-rule created

ansible@umaster:~/helm$ kubectl patch deploy --namespace kube-system tiller-deploy -p '{"spec":{"template":{"spec":{"serviceAccount":"tiller"}}}}'deployment.extensions/tiller-deploy patchedansible@umaster:~/helm$

From then on everything went perfectly and as described:

try the example mysql chart from here https://docs.helm.sh/using_helm/

like this:

helm install stable/mysql
and check with "helm ls"
helm lsansible@umaster:~/helm$ helm ls
NAME REVISION UPDATED STATUS CHART APP VERSION NAMESPACEdunking-squirrel 1 Thu Jan 3 15:38:37 2019 DEPLOYED mysql-0.12.0 5.7.14 defaultansible@umaster:~/helm$
and all is groovy
list pods with ansible@umaster:~/helm$ sudo kubectl get pods --all-namespaces -o wide

NAMESPACE NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
default dunking-squirrel-mysql-bb478fc54-4c69r 0/1 Pending 0 105s
kube-system coredns-86c58d9df4-mg8b9 1/1 Running 0 22h 10.244.0.11 umaster
kube-system coredns-86c58d9df4-zv24d 1/1 Running 0 22h 10.244.0.10 umaster
kube-system etcd-umaster 1/1 Running 0 22h 192.168.0.46 umaster
kube-system kube-apiserver-umaster 1/1 Running 0 22h 192.168.0.46 umaster
kube-system kube-controller-manager-umaster 1/1 Running 0 22h 192.168.0.46 umaster
kube-system kube-flannel-ds-amd64-2npnw 1/1 Running 0 15h 192.168.0.46 umaster
kube-system kube-flannel-ds-amd64-lpphn 1/1 Running 0 45m 192.168.0.43 ubuntu01
kube-system kube-proxy-b7rwv 1/1 Running 0 22h 192.168.0.46 umaster
kube-system kube-proxy-wqw8c 1/1 Running 0 45m 192.168.0.43 ubuntu01
kube-system kube-scheduler-umaster 1/1 Running 0 22h 192.168.0.46 umaster
kube-system tiller-deploy-8485766469-62c22 1/1 Running 0 2m17s 10.244.1.22 ubuntu01 ansible@umaster:~/helm$

The MySQL pod is failing to start as it has persistent volume claims defined, and I’ve not set up default storage for that yet – that’s covered in the next step/post 🙂

If you want to use or delete that MySQL deployment all the details are in the rest of the getting started guide – for the above it would mean doing a ‘helm ls‘ then a ‘ helm delete <release-name> ‘ where <release-name> is ‘dunking-squirrel’ or whatever you have.

A little more on Helm

Just running out of the box Helm Charts is great, but obviously there’s a lot more you can do with Helm, from customising the existing Stable Charts to suit your needs, to writing and deploying your own Charts from scratch. I plan to expand on this in more detail later on, but will add and update some notes and examples here as I do:

You can clone the Helm github repo locally:

git clone https://github.com/kubernetes/charts.git

and edit the values for a given Chart:

vi charts/stable/mysql/values.yaml

then use your settings to override the defaults:

helm install --name=donmysql -f charts/stable/mysql/values.yaml stable/mysql

using a specified name makes installing and deleting much easier to automate:

helm del donmysql

and the Helm ‘release’ lifecycle is quite docker-like:

helm ls -a
helm del --purge donmysql

There are some Helm tips & tricks here that I’m working my way through:

https://github.com/helm/helm/blob/master/docs/charts_tips_and_tricks.md

in conjunction with this Bitnami doc:

https://docs.bitnami.com/kubernetes/how-to/create-your-first-helm-chart/


Conclusion

For me and for now, I’m just happy that Helm, Tiller and Charts are working, and I can move on to automating these setup steps and some testing to my overall pipelines. And sorting out the persistent volumes too. After that’s all done I plan to start playing around with some of the stable (and perhaps not so stable) Helm charts.

As they said, this could well be “the best way to find, share, and use software built for Kubernetes” – it’s very slick!

Kubernetes – setting up the hosts

Introduction

This is Step 1 in my recent Kubernetes setup where I very quickly describe the process followed to build and configure the basic requirements for a simple Kubernetes cluster.

Step 2 is here https://www.donaldsimpson.co.uk/2018/12/29/kubernetes-from-cluster-reset-to-up-and-running/

and Step 3 where I set up Helm and Tiller and deploy an initial chart to the cluster: https://www.donaldsimpson.co.uk/2019/01/03/kubernetes-adding-helm-and-tiller-and-deploying-a-chart/

The TL/DR

A quick summary should cover 99% of this, but I wanted to make sure I’d recorded my process/journey to get there – to cut a long story short, I ended up using this Ansible project:

https://github.com/DonaldSimpson/ansible-kubeadm


which I forked from the original here:

https://github.com/ben-st/ansible-kubeadm

on the 5 Ubuntu linux hosts I created by hand (the horror) on my VMWare ESX home lab server. I started off writing my own ansible playbook which did the job, then went looking for improvements and found the above fitted my needs perfectly.

The inventory file here: https://github.com/DonaldSimpson/ansible-kubeadm/blob/master/inventory details the addresses and functions of the 5 hosts – 4 x workers and a single master, which I’m planning on keeping solely for master role.

My notes:

Host prerequisites are in my rough notes below – simple things like ssh keys, passwwordless sudo from the ansible user, installing required tools like python, setting suitable ip addresses and adding the users you want to use. Also allocating suitable amounts of mem, cpu and disk – all of which are down to your preference, availability and expectations.

https://kubernetes.io/docs/setup/independent/create-cluster-kubeadm/

ubuntumaster is 192.168.0.46
su – ansible
check history

ansible setup

https://www.howtoforge.com/tutorial/setup-new-user-and-ssh-key-authentication-using-ansible/
1 x master  - sudo apt-get install open-vm-tools-desktop - sudo apt install openssh-server vim whois python ansible - export TERM=linux re https://stackoverflow.com/questions/49643357/why-p-appears-at-the-first-line-of-vim-in-iterm
 - /etc/hosts:
127.0.1.1       umaster
192.168.0.43    ubuntu01
192.168.0.44    ubuntu02
192.168.0.45    ubuntu03
// slave nodes need:ssh-rsa AAAAB3NzaC1y<snip>fF2S6X/RehyyJ24VhDd2N+Dh0n892rsZmTTSYgGK8+pfwCH/Vv2m9OHESC1SoM+47A0iuXUlzdmD3LJOMSgBLoQt ansible@umaster
added to root user auth keys in .ssh and apt install python ansible -y
//apt install python ansible -y
useradd -m -s /bin/bash ansible
passwd ansible <type the password you want>

echo  -e ‘ansible\tALL=(ALL)\tNOPASSWD:\tALL’ > /etc/sudoers.d/ansibleecho  -e 'don\tALL=(ALL)\tNOPASSWD:\tALL' > /etc/sudoers.d/don
mkpasswd --method=SHA-512 <type password "secret">
Password:
$6$dqxHiCXHN<snip>rGA2mvE.d9gEf2zrtGizJVxrr3UIIL9Qt6JJJt5IEkCBHCnU3nPYH/
su - ansible
ssh-keygen -t rsa

cd ansible01/
vim inventory.ini
ansible@umaster:~/ansible01$ cat inventory.ini
[webserver]
ubuntu01 ansible_host=192.168.0.43
ubuntu02 ansible_host=192.168.0.44
ubuntu03 ansible_host=192.168.0.45

ansible@umaster:~/ansible01$ cat ansible.cfg
[defaults]
 inventory = /home/ansible/ansible01/inventory.ini
ansible@umaster:~/ansible01$ ssh-keyscan 192.168.0.43 >> ~/.ssh/known_hosts
# 192.168.0.43:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.43:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.43:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
ansible@umaster:~/ansible01$ ssh-keyscan 192.168.0.44 >> ~/.ssh/known_hosts
# 192.168.0.44:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.44:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.44:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
ansible@umaster:~/ansible01$ ssh-keyscan 192.168.0.45 >> ~/.ssh/known_hosts
# 192.168.0.45:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.45:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
# 192.168.0.45:22 SSH-2.0-OpenSSH_7.6p1 Ubuntu-4
ansible@umaster:~/ansible01$ cat ~/.ssh/known_hosts
or could have donefor i in $(cat list-hosts.txt)
do
ssh-keyscan $i >> ~/.ssh/known_hosts
done
cat deploy-ssh.yml

 – hosts: all
   vars:
     – ansible_password: ‘$6$dqxHiCXH<kersnip>l.urCyfQPrGA2mvE.d9gEf2zrtGizJVxrr3UIIL9Qt6JJJt5IEkCBHCnU3nPYH/’
  gather_facts: no
   remote_user: root

   tasks:

   – name: Add a new user named provision
     user:
          name=ansible
          password={{ ansible_password }}

   – name: Add provision user to the sudoers
     copy:
          dest: “/etc/sudoers.d/ansible”
          content: “ansible ALL=(ALL)  NOPASSWD: ALL”

   – name: Deploy SSH Key
     authorized_key: user=ansible
                     key=”{{ lookup(‘file’, ‘/home/ansible/.ssh/id_rsa.pub’) }}”
                     state=present

   – name: Disable Password Authentication
     lineinfile:
           dest=/etc/ssh/sshd_config
           regexp=’^PasswordAuthentication’
           line=”PasswordAuthentication no”
           state=present
           backup=yes
     notify:
       – restart ssh

   – name: Disable Root Login
     lineinfile:
           dest=/etc/ssh/sshd_config
           regexp=’^PermitRootLogin’
           line=”PermitRootLogin no”
           state=present
           backup=yes
     notify:
       – restart ssh

   handlers:
   – name: restart ssh
     service:
       name=sshd
       state=restarted

// end of the above file

ansible-playbook deploy-ssh.yml –ask-pass
results inLAY [all] *********************************************************************************************************************************************************************************************************************************************************************

TASK [Add a new user named provision] ******************************************************************************************************************************************************************************************************************************************
fatal:

[ubuntu02]

: FAILED! => {"msg": "to use the 'ssh' connection type
with passwords, you must install the sshpass program"}
for each node/slave/hostsudo apt-get install -y sshpass
ubuntu01 ansible_host=192.168.0.43
ubuntu02 ansible_host=192.168.0.44
ubuntu03 ansible_host=192.168.0.45

kubernetes setup
https://www.techrepublic.com/article/how-to-quickly-install-kubernetes-on-ubuntu/run install_apy.yml against all hosts and localhost too
on master:

kubeadm init

results in:root@umaster:~# kubeadm init
[init] using Kubernetes version: v1.11.1
[preflight] running pre-flight checks
I0730 15:17:50.330589   23504 kernel_validator.go:81] Validating kernel version
I0730 15:17:50.330701   23504 kernel_validator.go:96] Validating kernel config
    [WARNING SystemVerification]: docker version is greater than the most recently validated version. Docker version: 17.12.1-ce. Max validated version: 17.03
[preflight] Some fatal errors occurred:
    [ERROR Swap]: running with swap on is not supported. Please disable swap
[preflight] If you know what you are doing, you can make a check non-fatal with `–ignore-preflight-errors=…`
root@umaster:~#
doswapoff -a then try again
kubeadm init… wait for images to be pulled etc – takes a while

Your Kubernetes master has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

You should now deploy a pod network to the cluster.
Run “kubectl apply -f [podnetwork].yaml” with one of the options listed at:
https://kubernetes.io/docs/concepts/cluster-administration/addons/

You can now join any number of machines by running the following on each node
as root:

  kubeadm join 192.168.0.46:6443 --token 9e85jo.77nzvq1eonfk0ar6 --discovery-token-ca-cert-hash sha256:61d4b5cd0d7c21efbdf2fd64c7bca8f7cb7066d113daff07a0ab6023236fa4bc
root@umaster:~#

Next up…

The next post in the series is here: https://www.donaldsimpson.co.uk/2018/12/29/kubernetes-from-cluster-reset-to-up-and-running/ and details an automated process to scrub my cluster and reprovision it (form a Kubernetes point of view – the hosts are left intact).

Kubernetes – from cluster reset to up and running

This is Step 2 in a series of Kubernetes blog posts

Step 1 covers the initial host creation and basic provisioning with Ansible: https://www.donaldsimpson.co.uk/2019/01/03/kubernetes-setting-up-the-hosts/

and Step 3 is where I set up Helm and Tiller and deploy an initial chart to the cluster: https://www.donaldsimpson.co.uk/2019/01/03/kubernetes-adding-helm-and-tiller-and-deploying-a-chart/

These are notes on going from a freshly reset kubernetes cluster to a running & healthy cluster with a pod network applied and worker nodes connected.

To get to this starting point I provisioned 4 Ubuntu hosts (1 master & 3 workers) on my VMWare server – a Dell Poweredge R710 with 128GB RAM.

I then used this Ansible project:

https://github.com/DonaldSimpson/ansible-kubeadm

to configure the hosts and prep for Kubernetes with kubeadm:

https://kubernetes.io/docs/setup/production-environment/tools/kubeadm/create-cluster-kubeadm/

I’ll write about this in more detail in another post…

Please note that none of this is production grade or recommended, it’s simply what I have done to suit my needs in my home lab. My focus is on automating Kubernetes processes and deployments, not creating highly available bullet-proof production systems.

To reset and restore a ‘new’ cluster, first on the master instance – reboot and as a normal user (I’m using an “ansible” user with sudo throughout):


sudo kubeadm reset
(y)
sudo swapoff -a
sudo kubeadm init --pod-network-cidr=10.244.0.0/16

I’m passing that CIDR address as I’m using Flannel for pod networking (details follow) – if you use something else you may not need that, but may well need something else.

That should be the MASTER started, with a message to add nodes with:


  kubeadm join 192.168.0.46:6443 --token 9w09pn.9i9uu1ht8gzv36od --discovery-token-ca-cert-hash sha256:4bb0bbb1033a96347c6dd888c769ec9c5f6caa1b699066a58720ffdb97a0f3d7

which all sounds good, but the first most basic check produces the following error:


ansible@umaster:~$ kubectl cluster-info
To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
Unable to connect to the server: x509: certificate signed by unknown authority (possibly because of "crypto/rsa: verification error" while trying to verify candidate authority certificate "kubernetes")

which I think is due to the kubeadm reset cleaning up the previous config, but can be easily fixed with this:


mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

then it works and MASTER is up and running ok:


ansible@umaster:~$ sudo kubectl cluster-info
Kubernetes master is running at https://192.168.0.46:6443
KubeDNS is running at https://192.168.0.46:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy
To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

————- ADD NODES ——————

Use the command and token provided by the master on the worker node(s) (in my case that’s “ubuntu01” to “ubuntu04”). Again I’m running as the ansible user everywhere, and I’m disabling swap and doing a kubeadm reset first as I want this repeatable:

sudo swapoff -a
sudo kubeadm reset
sudo  kubeadm join 192.168.0.46:6443 --token 9w09pn.9i9uu1ht8gzv36od --discovery-token-ca-cert-hash sha256:4bb0bbb1033a96347c6dd888c769ec9c5f6caa1b699066a58720ffdb97a0f3d7

I think the token expires after a few hours. If you want to get a new one you can query the Master using:

https://kubernetes.io/docs/reference/setup-tools/kubeadm/kubeadm-token/

Or, as I’ve just found out, the more recent versions ok k8s provide “kubeadm token create –print-join-command”, which provide output like the following example that you can save to a file/variable/whatever:

kubeadm join 192.168.0.46:6443 --token 8z5obf.2pwftdav48rri16o --discovery-token-ca-cert-hash sha256:2fabde5ad31a6f911785500730084a0e08472bdcb8cf935727c409b1e94daf44

I believe options to specify json or alternative output formatting is in the works too.

That’s all that is needed, if you’ve not used this node already it may take a while to pull things in but if you have it should be pretty much instant.

When ready, running a quick check on the MASTER shows the connected node (ubuntu01) and the Master (umaster) and their status:


ansible@umaster:~$ sudo kubectl get nodes --all-namespaces
NAME       STATUS     ROLES    AGE     VERSION
ubuntu01   NotReady   <none>   27s     v1.13.1
umaster    NotReady   master   8m26s   v1.13

The NotReady status is because there’s no pod network available – see here for details and options:

https://kubernetes.io/docs/setup/independent/create-cluster-kubeadm/#pod-network

so apply a pod network (I’m using flannel) like this on the Master only:


ansible@umaster:~$ sudo kubectl apply -f https://raw.githubusercontent.com/coreos/flannel/bc79dd1505b0c8681ece4de4c0d86c5cd2643275/Documentation/kube-flannel.yml
clusterrole.rbac.authorization.k8s.io/flannel created
clusterrolebinding.rbac.authorization.k8s.io/flannel created
serviceaccount/flannel created
configmap/kube-flannel-cfg created
daemonset.extensions/kube-flannel-ds-amd64 created
daemonset.extensions/kube-flannel-ds-arm64 created
daemonset.extensions/kube-flannel-ds-arm created
daemonset.extensions/kube-flannel-ds-ppc64le created
daemonset.extensions/kube-flannel-ds-s390x created

Then check again and things should look better now they can communicate…


ansible@umaster:~$ sudo kubectl get nodes --all-namespaces
NAME       STATUS   ROLES    AGE     VERSION
ubuntu01   Ready    <none>   2m23s   v1.13.1
umaster    Ready    master   10m     v1.13.1
ansible@umaster:~$

Adding any number of subsequent nodes is very easy and exactly the same (the pod networking setup is a one-off step on the master only). I added all 4 of my worker vms and checked they were all Ready and “schedulable”. My server coped with this no problem at all. Note that by default you can’t schedule tasks on the Master, but this can be changed if you want to.

That’s the very basic “reset and restore” steps done. I plan to add this process to a Jenkins Pipeline, so that I can chain a complete cluster destroy/reprovision and application build, deploy and test process together.

The next steps I did were to:

  • install the Kubernetes Dashboard to the cluster
  • configure the Kubernetes Dashboard and fix permissions
  • deploy a sample application, replicaset & service and expose it to the network
  • configure Heapster

which I’ll post more on soonish… and I’ll add the precursor to this post on the host provisioning and kubeadm setup too.

Wooden boards

A few pics of some roughly milled Ash planks a friend gave us, which I planed/thicknessed and cut to length & height to create kitchen kick-boards.

Followed by a few pics of a chopping board I finished off at the same time.

The planks had been sitting around the yard for quite a while… here they are after a quick initial run through the planer:

Close up after sanding and applying a load of Danish oil:

Drying in the sun:

The boards are in place now and I’ll add some pics if the kitchen is ever clean enough 🙂


Some close up pics of a couple of chopping board made from a sleeper another friend gave me about 5 years ago – he’d had it for yonks so it must be pretty old wood. I left them extra chunky so when they get too scored and cut I can resurface them several times:

Pin It on Pinterest

%d bloggers like this:
